DLSD
Zhongke electric
*High background magnetic field strength.The rated background magnetic field strength of the magnetic
separator reaches 1.6 T,and the surface field strength of the magnetic matrix can reach 3.18 T,which can effectively
separate weak magnetic minerals.
*Raw ore enters the separation zone equipped with magnetic matrix from bottom to top.The direction of iron
unloading and pressurized flushing is opposite to the ore feeding direction,allowing coarse particles to be easily
flushed out,effectively preventing clogging of the magnetic medium.
*The excitation coil adopts advanced fully enclosed insulation curing technology,featuring excellent
waterproof,dust-proof,and anti-corrosion performance,ensuring the device can operate in various coarse
environments.
*Meanwhile,the coil uses a water cooling method,resulting in low temperature rise,which greatly extends the
service life of the coil.
*The unique magnetic system structure and advanced magnetic matrix structure enable the ore feeding particle
size to reach 20 mesh,simplifying on-site classification operations.
*An isolation transformer is adopted to prevent pollution to the power grid during equipment operation.The
secondary output of the transformer is floating with low voltage,making on-site operations safer and more reliable.
*All working processes and valve actions of the device are fully automatically controlled by PLC. This facilitates operation and adjustment by on-site personnel to achieve better separation effects and realizes intelligent operation control of the equipment.
